Solid Complementary Conductor™ Technology
Ferrite Insulation Technology™
Dual electrostatic shielding
Foamed polyethylene dielectric
Gold-plated RCA connectors
Flexible TPE outer jacket
Conductor Material: Solid Enamelled 99.999% Oxygen-Free Copper
Conductor Construction: (1 × 1/0.511 + 1 × 1/0.254) [24 AWG]
Screening Material: Ferrite Jacket, Aluminium Mylar Wrap and 100% Shield Braid
Dielectric: Foamed Polyethylene
Loop Resistance: 0.081 Ω/m
Parallel Capacitance: 66 pF/m
Loop Inductance: 0.38 μH/m
Dissipation Factor: 0.0124 @10kHz
Characteristic Impedance: 75 Ω
Outside Diameter: 6 mm
Jacket Finish: Stone Grey TPE
Available Lengths
0.75 m
1.5 m
3.0 m
Warranty
Performance Audio Interconnect cable is backed by a 2-year manufacturer's warranty, extended to
5 years when you register your product. It's one more reason to connect with confidence.
