2.5 mm² conductor cross-sectional area
X-Tube Plus™ Technology
99.999% oxygen-free copper conductors
Low-loss LDPE dielectric
Airloc™ cold-weld terminations
Banana plug and spade terminated options
Available in pre-terminated and reel formats
Technical Specifications
Conductor Material: Stranded 99.999% Oxygen-Free Copper
Construction: 10 × 19/0.13 mm
Stranded Diameter: 2.1 mm
Cross-Sectional Area: 2.5 mm² (AWG14)
Dielectric: LDPE
Loop Resistance: 0.017 Ω/m
Parallel Capacitance: 26 pF/m
Loop Inductance: 0.56 μH/m
Dissipation Factor: 0.0009 @10kHz
Characteristic Impedance: 147 Ω
Jacket Outside Diameter: 3.96 × 9 mm
Jacket Finish: Translucent White
Available Lengths
Pre-Terminated Speaker Cable
2 m
3 m
5 m
Warranty
Performance Speaker cable is backed by a 2-year manufacturer's warranty, extended to 5 years
when you register your product. It's one more reason to connect with confidence.
